Model 513

Download the Specs Model 513.pdf


The Model 513 has been redesigned to be a reliable performer for metal banding, tubing, extrusions, plastic strap and light-weight cable. Prepared for abusive environments, this unit has a strong 1/2” plate steel housing…

Material Reference

The following are materials that are commonly processed through the Model 513. Contact a Sweed Representative to determine if the Model 513 will fit your application.

  • 3/8” x .125” steel band
  • 1/2” x .093” steel band
  • 3/4” x .093” steel band
  • 5/16” x .093” steel band
  • 1” x .078” steel band
  • 1 1/4” x 046” steel band
  • All sizes of plastic/PET strap

Performance Data

  • Electric Motor Power: 2 HP
  • Infeed Speed: 90 FPM
  • Cut Length: 3"
  • Infeed Opening: 5 5/8" x 1 5/8"

Dimensional Data

  • Infeed Opening: 5 5/8" x 1 5/8"
  • Overall: 48” x 29” x 23”
  • Weight: 1000 lbs.

Gallery

Sweed Scrap Chopper Model 513

How it Works

Just introduce the material (banding) into the infeed funnel. The feedworks (pinch rolls) will then grab the material and pull it into the rotating knife path. The feedworks will continue to pull at a rate of 90 FPM until the material is consumed or the operator releases the feedworks via the release lever.
